Flex PCB for an “Taped-Automatic Assembly” like ASIC packaging. Targetting the 56 pin ASIC switch chip.
ASIC chip containing the first generation systolic array.
Single Ethernet connector Pmod test PCB.
Full ASIC chip featuring a 4-port 100Mbps Ethernet switch and a beacon broadcasting over the local network. Tape-out number 10, targetting the gf180mcuD node.
Ethernet Beacon broadcasting over 100Mbps Ethernet. Tapeout-number 9, targetting the gf180 node .
Test design for the OCD 256x8 SRAM macro. Tape-out number 8, targetting the gf180.
3-port 100Mbps Ethernet Switch. Tape-out number 7, targetting the gf180mcuD node.
Accelerator wrapper for interfacing over 100Mbps Ethernet. Tape-out number 6, targetting the gf180mcuD node.
Analog 33Mhz oscillator. Tape-out number 5, targetting the sky130A node.
Frequency optimized custom bfloat16 multiplier. Tape-out number 4, targetting the ihp130cmos5l node.
Initial global placement of the second generation systolic array. Tape-out number 3, targetting the ihp130g2 node.
Second generation systolic array, using custom designed bfloat16 floating point math with full DFT infrastrucutre including scan-chains accessible over JTAG. Tape-out number 3, targetting the ihp130g2 node.
Silicon Proven at A0. First generation systolic array, using signed integers with in silicon debug infrastrucutre accessible over JTAG. Tape-out number 2, targetting the gf180mcuD node.
BLAKE2s hashing accelerator. Tape-out number 1, targetting the sky130A node .
Custom STM32H7 development board designed as a 10 year anniversary present.There are no articles to list here yet.
